The Semi Automatic Cotton Tissue Machine is an efficient and cost-effective solution for producing disposable cotton towels, facial tissues, and cleansing wipes. Designed for small and medium-sized businesses, it offers stable performance, compact structure, and easy operation with low investment requirements.
Products
Semi Automatic Cotton Tissue Machine
The Semi Automatic Cotton Tissue Machine is designed fo…
Capacity:
3–5 rolls/min
Fold:
Roll folding
Packing Size:
Roll width 100 mm (customizable)
Control:
Frequency Inverter Speed Control
Share With:
Details
Paramters
|
Finished product size
|
Hole spacing 200mm (fine adjustment is allowed)
|
|
Transmission mode
|
Variable frequency control motor speed regulation
|
|
Applicable raw materials
|
Coiled,35-90gsm: spunlaced non-woven fabric
|
|
Raw material diameter
|
≤ Ф800 mm
|
|
Width of raw materials
|
≤ 200mm
|
|
Finished product size
|
The width of the soft towel roll after folding is 10cm
|
|
Raw paper core
|
Inner diameter p 76.2mm (= 3 “)
|
|
Processing capacity
|
3-5 rolls/minute
|
|
Total power required
|
220V 50HZ 2.2 KW
|
|
Machine weight
|
300kg
|
|
Overall dimensions
|
L2200*W1800*H1200mm
|
Finish Product
The finished rolls produced by the Semi Automatic Cotton Tissue Machine feature smooth edges, uniform perforation, and tight, consistent winding. Each roll is neatly formed with stable tension control, ensuring easy tearing and clean separation.
Also known as a roll cotton towel machine or towel rolling machine, this equipment is ideal for small-scale enterprises. It can process disposable non-woven products such as soft towels, cleansing towels, and face towels with high consistency and efficiency.
With small investment, compact footprint, and support for two-phase electricity, the machine is easy to install and operate. Thanks to precise winding and accurate counting, the final products maintain a soft texture, professional appearance, and are easy to store, transport, and use.
Key Advantages
Rack
Belt synchronous conveying with dual tension control.Ensures accurate product size and stable operation.
Point Breaking
Gear-type stepless transmission with adjustable pitch length.Smooth perforation with low noise.
Easy Operation
Frequency inverter speed control with optimized wiring.Automatic winding and shutdown for simple operation.
Spiral Winding
Screw and pneumatic winding system.Ensures neat rolls, high speed, and accurate counting.
